Ella Transfer32 32x52: Wide-Seat Transfer Tub With Three-System Packages

The Ella Transfer32 is the wide-seat 52 inch model in the wheelchair-accessible Transfer family. Its actual size is 32 inches wide by 52 inches long by 40 inches tall, and the extra 2 inches over the Transfer30 go into a roomier 24 inch wide molded seat. It is also the smallest Transfer model to offer a three-system package that combines air massage, hydro massage and Infusion microbubble therapy in one tub.

Dimensions and Capacity

• Actual size: 32 by 52 by 40 inches. Seat width: 24 inches.
• Comparison chart interior figures: 16 7/8 inch seat length, 43 3/4 inch interior length, 19 3/4 inches from seat to overflow, 17 inches from seat to footwell, 19 1/2 by 17 1/2 inch footwell.
• Water: 107 gallons unoccupied, 45 to 65 gallons occupied, per the current spec sheet.
• Weight: 215 pounds net, 373 pounds shipping, in a 35 by 55 by 50 inch crate.
• Door opening angle: 172 degrees with a 20 inch swing clearance callout on the drawing.

Ella's Bubbles positions the Transfer32 for larger body types who want more hip room than the 22 inch seat of the Transfer30 while staying inside a 52 inch footprint; see weight limits and bariatric options. The included 8 inch extension panel finishes it in a 60 inch alcove.

How the Hydro and Air Jets Are Arranged

Upper jets work the back, hips and thighs and lower jets the feet and calves, and the current spec sheet lists the jets by package: the Hydro Massage and Hydro + Hydro Foot packages list 22 hydro jets (16 seat and 6 foot), while the Air + Hydro package lists 17 air jets (11 seat including 2 bidet, 6 foot) and 11 hydro jets (5 back, 6 foot). In other words, the jet count follows the package on your order rather than the model alone; see jet counts by model and package.

Three-System Capability and Circuits

The Transfer32 package menu on the current spec sheet is:

1. Air + Hydro (LED chromatherapy included)
2. Air + Hydro Massage + Microbubble Therapy (LED included)
3. Hydro + Hydro Independent Foot Massage (LED included)
4. Hydro Massage + Microbubble (LED included)
5. Hydro Massage (no LED)
6. Soaking

The three-system package runs a 4.5 amp three-speed air pump with auto purge, a 7 amp hydro pump with in-line heater and ozone, and a 1 HP 7.3 amp microbubble pump with its pressure vessel and agitator valve. Every package requires dedicated GFCI-protected 115/120 V, 60 Hz lines, and a package with several pumps will need more than one 20 amp circuit; see electrical requirements by model and work from the schematic for your package. A heated seat and backrest and a digital controller are optional on every package.

Transfer30 and Transfer32 Side by Side

Watch: Wheelchair Accessible Transfer Walk-In Tubs in 30x52 & 32x52 Sizes with chapters and a full transcript.

This video compares the two 52 inch models: the 32 by 52 with its 24 inch seat and the 30 by 52 with its 22 inch seat, both with about 44 inches of interior and a 15 1/2 inch seat length, and a 14 1/2 inch soaking depth quoted for the 32. It then shows the L-door with the two-latch lock, the 17 jet air massage with auto purge, hydro with the dial and in-line heater, foot jets, ozone, the independent foot massage option, dual 2 inch drains, the 5-piece faucet, the microbubble option, and chromatherapy. Where the rounded figures differ from the spec sheet, the sheet governs.

Independent Foot Massage

Watch: Wheelchair-Accessible Transfer Acrylic Walk-In Tub with L-Shaped Door with chapters and a full transcript.

This video shows the L-shaped outward-swing transfer tub with the independent foot massage feature. The foot massage runs on its own separate pump with its own intensity control dial, so there is no need to fill the whole tub to enjoy the foot and calf jets; filling the footwell to seat level is enough. The video also shows the extra-wide L-shaped door fitting over a toilet, the two-latch gear and shaft lock, the dual drains, the LED chromatherapy included with the package, the optional heated seat and backrest, the four-fold glass screen as a shower curtain alternative, and the optional shower column with its adjustable rain head and extendable hand shower. With the Hydro + Hydro Foot package the tub ships with one in-line heater connected to the lower jets and an ozone system connected to the upper jets.

Door, Panels and Faucet Options

Watch: Ella's Acrylic Transfer Walk-In Tub: Wheelchair Accessible & Senior Friendly with chapters and a full transcript.

This options tour lists what can be built into a Transfer tub: the extra-wide L-shaped door with the two-latch gear and shaft lock, low threshold and textured floor, the optional heated seat and backrest, a choice of the five-piece or two-piece fast-fill faucet set each with a multi-function detachable hand shower, easy-touch function buttons, aromatherapy, deck and wall-mounted grab bars with a soft-grip handle, microbubble therapy, three-speed air massage with auto purge, adjustable hydro massage with in-line heater, independent foot massage, ozone sterilization, chromatherapy on dual-massage tubs and the dual drain system. The current Transfer32 spec sheet headlines the five-piece faucet, rated up to 18 gallons per minute at 60 PSI under ideal plumbing, with two 5 foot 3/4 inch supply lines and a pull-out hand shower. Included hardware matches the family: removable front apron with two access panels, one reversible end panel, the 8 inch extension panel, deck and wall grab bars, and two 2 inch four-port drains with two overflows and two openers.

Transfer32 Versus Monaco

Both are 32 by 52 inch outward-swing tubs that take an extension panel for a 60 inch alcove, so the choice is about the door and the seat. The Transfer32 has the L-shaped door with a two-latch lock, opens to 172 degrees and leaves no sidewall beside its 24 inch seat, which is what makes a wheelchair transfer possible. The Monaco has the U-shaped outward door with a three-latch lock, opens to 165 degrees on its drawing and lists a 23 inch seat on the comparison chart, so it keeps a low sidewall next to the seat. If the bather transfers from a chair or slides in sideways, choose the Transfer32; if the bather steps in and prefers the U-door look, the Monaco is the comparable size. The wider family comparison is in the Transfer tub family guide.

Therapy Packages and Hip Jets Compared with the Monaco

Choosing the Transfer32 over the Monaco does not mean giving up therapy options. The Transfer32 can be configured with the same therapy package and the same accessories as the Monaco, so a hydro massage, air massage, independent foot massage and chromatherapy lighting build is available on either tub.

The one thing the Transfer32 cannot take is the set of four hydro massage water jets aimed at the hips that the Monaco offers. The Transfer32's frame and structural configuration do not leave room for extra water jets in the hip area. This is a frame limitation rather than a package limitation, so it cannot be solved by ordering a bigger package or by adding jets after delivery. See can I add jets or a heated seat to my tub later for why jets are set at the factory.

In exchange, the Transfer32 gives you a longer seat than the Monaco. That length is part of what makes the tub wheelchair accessible and gives a bather more room to shift position while seated. Whether the extra length lets you lean back far enough for the upper jets to reach your shoulders depends on your height and torso length, so check the seat and backrest dimensions on both spec sheets against your own measurements.

If hip massage is the main reason you are buying a jetted tub, the Monaco is the stronger choice. If the bather needs a transfer seat, the Transfer32 with the same package covers everything else. Ask your dealer to configure both tubs with the identical package so you are comparing like for like.
