ELLA WALK IN BATHTUBS

Welcome to Ella brand walk-in tub full product line quick reference page for all Ella bathtubs with the door. Ella brand walk-in bathtubs come in nine (9) different categories or door styles as follow.

Click on each walk-in tub image link to see a product page and details. Or click on the link About Ella Walk-In Tubs to learn more about all Ella brand walk-in tubs.

Stainless Steel & Tempered Glass Inward Swing Door Walk-In Tubs

Ultimate

30″W x 60″L
Seat size: 21″

Deluxe

30″W x 55″L
Seat size: 19.75″

Royal

32″W x 52″L
Seat size: 23.75″

Elite

30″W x 52″L
Seat size: 21.75″

Petite

28″W x 52″L
Seat size: 19.75″

	Elite	Petite	Royal	Deluxe	Companion	Ultimate
Dimensions of Tub WxLxH	29.75x52.25x38	27.75x52.25x38	31.75x52.25x38	29.5x55x38	30.25x59.75x37	29.75x59.75x38
Dimensions of Crate WxLxH	34x57x46	34x57x46	36x57x46	34x59x46	35x65x45	33x63x47
Extension Panel	7"	7"	7"	5"	N/A	N/A
Threshold Height	6"	6"	6"	7"	8"	6"
Threshold Lowering Option	4"	4"	4"	6"	6"	4"
Seat Width	21.75"	19.75"	23.75"	19.75"	20.25"	21"
Seat Height	15"	15"	15"	15"	15"	15"
Width of Door	16.25"	16.25"	16.25"	16.25"	16.25"	16.25"

	Elite	Petite	Royal	Deluxe	Companion	Ultimate
Gallons USA (Unoccupied)	75	70	80	90	95	95
Gallons USA (Occupied)	45-65	35-55	45-70	55-75	45-65	55-85
Suggested Water Heater*	75	75	75	75	75	75
Approximate Drainage Time**	80 Seconds	80 Seconds	80 Seconds	80 Seconds	120 Seconds	80 Seconds
Drain/Door Location	Right or Left	Right or Left	Right or Left	Right or Left	Center	Right or Left
Product Net Weight LBS (soaking/dual)***	165/190	160/185	170/195	175/195	190/215	N.A/215
Product Shipping Weight LBS (soaking/dual)***	225/250	220/245	230/255	230/255	285/310	N.A/310
Suggested water heater size for a household with only a single bather. A household with any additional bathers should consider the next size available water heater. Approximate Drainage Time is under ideal plumbing conditions, your drainage times may vary.**Net and shipping weight depends on what packages is ordered

	Elite	Petite	Royal	Deluxe	Companion	Ultimate
Grab Bar(s)	2	1	2	2	1	2
One End Panel Included	Yes	Yes	Yes	Yes	Yes	Yes
Number of Access Panels	2	2	2	2	2	2
Hydro Jets	14	14	14	12	18	17
Air Jets	16	10	16	10	15	17
Removable Swivel Tray	Yes	Yes	Yes	N/A	N/A	Yes

U-Shape Acrylic & Tempered Glass Outward Swing Door

Monaco

32″W x 52″L
Seat size: 23″

Front entry

32″W x 40″L
Seat size: 20″

Mobile

26″W x 45″L
Seat size: 19″

Lounger

27″W x 60″L
Seat size: 19.5″

Ella Walk In Bathtubs Capri

Capri

30″W x 52″L
Seat size: 20.75″

	Malibu/Zen	Monaco/Chi	Lounger	Mobile	Front Entry
Dimensions of Tub WxLxH	29.5x52x43	31.5x52x43	26.75x60.25x43	25.75x45x42	31.5x40x42
Dimensions of Crate WxLxH	32x54x50	34x54x50	28x62x50	28x47x50	34x42x50
Threshold Height	6"	6"	6"	6"	5"
Threshold Lowering Option	4"	4"	4"	6"	5"
Seat Width	20"	23"	19.75"	19"	24"
Seat Height	17"	17"	17"	17"	16"
Width of Door	20"	20"	19.75"	20"	20"

	Malibu/Zen	Monaco/Chi	Lounger	Mobile	Front Entry
Gallons USA (Unoccupied)	90	95	85	70	70
Gallons USA (Occupied)	55-75	85	45-65	35-55	25-55
Suggested Water Heater*	75	75	75	75	75
Approximate Drainage Time**	80 Seconds	80 Seconds	80 Seconds	80 Seconds	140 Seconds
Drain/Door Location	Right or Left	Right or Left	Right or Left	Right or Left	Center
Product Net Weight LBS (soaking/dual) ***	187/201	192/212	187/209	149/172	137/157
Product Shipping Weight LBS (soaking/dual) ***	313/342	331/357	340/364	260/282	245/265

	Malibu/Zen	Monaco/Chi	Lounger	Mobile	Front Entry
Grab Bar(s)	2	2	1	1	0
One End Panel Included	Yes	Yes	Yes	Yes	No
Number of Access Panels	2	2	2	1	2
Hydro Jets	13	13	9	9	13
Air Jets	16	16	14	14	14

L-Shape Aluminum & Acrylic Outward Swing Door Walk-In Tubs

Wheelchair Accessible Walk In Tubs

TransferXXXL

36″W x 55″L
Seat size: 31"

Transfer60

30″W x 60″L
Seat size: 22"

Transfer32

32″W x 52″L
Seat size: 24.5"

Transfer

30″W x 52″L
Seat size: 22"

Transfer26

26″W x 52″L
Seat size: 19.5"

Wheelchair Accessible Walk In Tubs

L-Shape Aluminum & Acrylic Outward Swing Door Walk-In Tubs

TransferXXXL

36″W x 55″L
Seat size: 31″

Transfer60

30″W x 60″L
Seat size: 22″

Transfer32

32″W x 52″L
Seat size: 24.5″

Transfer

30″W x 52″L
Seat size: 22″

Transfer26

26″W x 52″L
Seat size: 19.5″

	Transfer	Transfer32	Transfer26	Transfer60	TransferXXXL
Dimensions of Tub WxLxH	29x52x42	32x52x42	26x52x42	30x60x42	36x55x42
Dimensions of Crate WxLxH	32x54x50	34x54x50	30x54x50	32x62x50	38x60x50
Threshold Height	7"	7"	7"	7"	7"
Threshold Lowering Option	4.5"	4.5"	4.5"	4.5"	4.5"
Seat Width	22"	24.5"	20"	22"	29"
Seat Height	17"	17"	17"	17"	17"
Width of Door	36" L Shaped	36" L Shaped	36" L Shaped	36" L Shaped	36" L Shaped

	Transfer	Transfer32	Transfer26	Transfer60	TransferXXXL
Gallons USA (Unoccupied)	75	80	65	90	110
Gallons USA (Occupied)	45-55	45-65	30-40	55-75	65-85
Suggested Water Heater*	75	75	75	75	75
Approximate Drainage Time**	80 Seconds	80 Seconds	80 Seconds	80 Seconds	120 Seconds
Drain/Door Location	Right or Left	Right or Left	Right or Left	Right or Left	Right or Left
Product Net Weight LBS	220	220	220	220	240
Product Shipping Weight LBS	300	300	300	300	320

	Transfer	Transfer32	Transfer26	Transfer60	TransferXXXL
Grab Bar(s)	2	2	2	2	2
Number of Access Panels	3	3	3	3	3
Hydro Jets	13	13	13	13	13
Air Jets	16	16	16	16	16

Two Seat Walk In Tubs

Big4Two

36″W x 80″L
Seat size: 21″/26″

Tub4Two

32″W x 60″L
Seat size: 19″/22″

Companion

30″W x 60″L
Seat size: 20″

	Tub4Two	Big4Two	Companion
Dimensions of Tub WxLxH	31.75 x 60 x 42	36x80 x 42	30.25x59.75x37
Dimensions of Crate WxLxH	33 x 62 x 50	38 x 73 x 50	35x65x45
Threshold Height	6"	6"	9"
Threshold Lowering Option	6"	6"	6"
Seat Width	19.25"	21"/26"	20.25"
Seat Height	17"	17"	15"
Width of Door	19.75"	19.75"	16.5"

	Tub4Two	Big4Two	Companion
Gallons USA (Unoccupied)	100	143	95
Gallons USA (Occupied)	50-70	n/a	45-65
Suggested Water Heater*	75*	80*	75*
Approximate Drainage Time**	120 Seconds	150 Seconds	120 Seconds
Drain/Door Location	Center	Center	Center
Product Net Weight LBS	240	295	260
Product Shipping Weight LBS	380	483	360
Suggested water heater size for a household with only a single bather. A household with any additional bathers should consider the next size available water heater. *Approximate Drainage Time is under ideal plumbing conditions, your drainage times may vary.

	Tub4Two	Big4Two	Companion
Grab Bar(s)	0	0	1
Thermostatic Control Valve	No	No	Yes
Water Supply Lines	1/2"	1/2"	1/2"
Pull Out Hand Mixer Hose	Yes	Yes	Yes
Textured Slip Resistant Floor	Yes	Yes	Yes
Number of Access Panels	3	3	4
Hydro Jets	22	26	18
Air Jets	16	10	10
In-line Water Heater	D	D	D
Ozone Sterilization	D	D	D
LED Chromatherapy	D	D	D
Heated Seat	Optional	Optional	Optional
Options: S - Soaking, D - Dual Massage (hydro & air)
