Door latch or handle trouble: correct handle installation, alignment, and replacements

Walk-in tub door latch or handle trouble usually has one of two causes: the handle was installed in the wrong orientation on the latch mechanism, or the tub is slightly out of level so the door no longer meets the frame squarely. If your door handle feels loose, will not rotate into the locked position, or the door does not pull tight against the seal, both causes are correctable at home, and replacement latch parts are available through ellasbubbles.com/support.

Know Your Latch System

Not sure which door you have? Our guide to which door each Ella tub uses lists every model.

Correct Handle Installation on Outward-Swing Doors

Proper installation of the handle is vital to correct door alignment and a waterproof seal. Follow the sequence from the video: Watch: Ellas Bubbles: Proper Handle Installation-Outswing Doors with chapters and a full transcript.

1. Line up the tabs as shown, then place the handle onto the latch mechanism in the correct placement.
2. Insert and hand tighten the locking bolt, then secure it firmly with a socket wrench.
3. Attach the chrome cover and hand tighten it.
4. Check the orientation: the handle should always face away from the hinges when unlocked, and the handle should face toward the hinges when locked.

An incorrectly oriented handle will result in improper door closures and potential leaks, so this one check resolves many latch complaints on its own.

This second upload covers the same handle installation on the outward door: line up the tabs, seat the handle on the latch, insert and hand tighten the locking bolt, secure it with a socket wrench, and fit the chrome cover, with the handle facing away from the hinges when unlocked. Keep whichever link works best for you. Watch: Ella's Bubbles: Proper Handle Installation with chapters and a full transcript.

If the Door Rubs or the Latch Will Not Engage: Check Leveling

Watch: Ellas Bubbles: Proper Door Alignment with chapters and a full transcript.

When the door rubs the jamb, it is often because the tub has bowed down slightly. Raising the tub from the center by extending the center leveling leg opens the door frame back up so the door clears the jamb. Ella tubs have at least six leveling legs, and it is imperative that each leg rests solidly on the ground with no gaps. If the tub is not level, the door will not be able to close securely and can leak. Adjust each leg so it rests firmly on the floor, take careful measurements on all sides of the tub, and re-check until the door closes smoothly into a watertight seal. Please keep in mind that misleveling is the number one cause of door leaks and is excluded from warranty coverage, so this check protects you twice. The full procedure is in our article on fixing a door that rubs the frame.

Inward-Swing Stainless Steel Door: Handle Tension and Latch Replacement

On the stainless steel inward-swing door, the chrome handle is held by a lock nut behind the front apron. A handle that no longer sits flush has a loose nut, and a door that is hard to open or close has a nut that is too tight; our lock nut and hinge adjustment guide shows the adjustment on video.

The clip above is the dedicated latch replacement video for the inward-swing stainless steel door. Watch it through once before removing anything so you can see the sequence, and have the replacement latch assembly in hand before you start. Watch: Ella's Bubbles: Latch Replacement for Inward Swing Stainless Steel Door Walk In Safety Bathtubs on its own page.

A Few Habits That Protect the Latch and Door

• Never lean on or put weight on the door. The door is designed to hold its own weight only, and the door and seal warranty depends on it.
• Never force the door open after a bath. Inward doors are held by water pressure by design, so wait until the tub is completely drained. Our article on why the door will not open until the tub drains explains both door types.
• Keep the seal and frame clean so the latch does not have to fight debris to compress the gasket.

Requesting a Replacement Latch or Handle

Latch mechanisms, handles, and their covers vary by model and production year. Open a ticket at ellasbubbles.com/support with your serial number, where the tub was purchased, and a photo of the part your handle closes onto, and the team will identify the exact latch part and arrange shipment. When you request a latch, mention that you need the complete assembly, the hard plastic receiver, the silicone cover and the hardware, so everything arrives together. Broken latch receivers, handles and locking parts are all replaceable, and the team is glad to walk you through the fitting, including by live video.

Related Guides

• Door Handle Loose, Wobbly or Hard to Turn: Tightening the Bolt Under the Cap and Adjusting the Lock Nut
• Found a Small Soft Rubber Piece in the Tub? It Is the Door Latch Bumper
• Water Drips Through the Striker Plate Pin Hole: Is a Part Missing?
• Door Hinge Pins Sliding Out or a Missing Hinge Cap: Getting the Right Replacement
• How Do Walk-In Tubs Work, From the Door Seal to the Drain?
• Can I Still Order a Replacement Door Latch or Older Handle?

Common Questions

For anything specific to your model or serial number, open a ticket at ellasbubbles.com/support or call (800) 480-6850, and please attach photos so the team can help you quickly.
