Elite vs Royal: Walk-In Tub Comparison
The Ella Elite and the Ella Royal side by side, using the actual dimensions from the spec sheets and technical drawings rather than nominal sizes. The profiles cover therapy packages, videos and installation notes for each tub.
VS
| Door style | Stainless steel removable inward-swing door | Stainless steel removable inward-swing door |
| Door swing | Inward | Inward |
| Seats | One bather | One bather |
| Actual size (W x L x H) | 30" x 52" x 35" | 31.5" x 52" x 35" |
| Seat | 22" x 12 1/4 in. | 23" x 12 1/4 in. |
| Interior length | 45 in. | 45 1/4 in. |
| Seat to overflow (soaking depth) | 15 1/2 in. | 15 1/2 in. |
| Seat to footwell | 15 in. | 15 in. |
| Footwell | 17 W by 20 1/2 L | 19 1/2 W by 20 L |
| Net weight | 205 lb | 230 lb |
| Shipping weight | 230 lb | 320 lb |
| Crate size (W x L x H) | 32" x 54" x 50" | 36" x 57" x 46" |
| Water to overflow, unoccupied | 75 gal | 100 gal |
| Water with a bather (typical) | 35-55 gal | 45-65 gal |
What is different
- The Royal is 1 1/2 in. wider than the Elite (31 1/2 in. vs 30 in.).
- Both are 52 in. long.
- Both are 35 in. tall.
- They share the same door design: stainless steel removable inward-swing door.
- To the overflow, the Elite holds about 75 gallons and the Royal about 100, which matters for water heater sizing.
- Net weights are 205 lb (Elite) and 230 lb (Royal).
Common questions
Which is bigger, the Elite or the Royal?
The Royal has the larger footprint at 31.5" x 52" x 35", against 30" x 52" x 35" for the Elite.
Do the Elite and the Royal have the same door?
Yes. Both use the stainless steel removable inward-swing door, so the same operation, seal and latch guides apply to either tub.
How much water do the Elite and the Royal hold?
To the overflow when empty, the Elite holds about 75 gallons and the Royal about 100 gallons; with a bather the typical ranges are 35-55 and 45-65 gallons. Size your water heater to the larger figure.
Read the full profiles
Add a third model to this comparison → · Dimensions by model · Which door does my tub have?
Want help choosing?
Your Ella dealer or the team at (800) 480-6850 can walk you through both tubs for your space and needs.
