Ultimate vs Companion: Walk-In Tub Comparison
The Ella Ultimate and the Ella Companion side by side, using the actual dimensions from the spec sheets and technical drawings rather than nominal sizes. The profiles cover therapy packages, videos and installation notes for each tub.
VS
| Door style | Stainless steel removable inward-swing door | Stainless steel removable inward-swing door |
| Door swing | Inward | Inward |
| Seats | One bather | Two bathers |
| Actual size (W x L x H) | 29.625" x 59.50" x 35.75" | 32" x 60" x 40" |
| Seat | 21" x 16 in. | 23" and 25" |
| Interior length | 51 1/4 in. | 54 5/8 in. |
| Seat to overflow (soaking depth) | 18 1/2 in. | 18 7/8 in. |
| Seat to footwell | 15 in. | 17 in. |
| Footwell | 19 W by 21 L | not listed |
| Net weight | 220 lb | 251 lb |
| Shipping weight | 350 lb | 300 lb |
| Crate size (W x L x H) | 33" x 63" x 47" | 34" x 62" x 50" |
| Water to overflow, unoccupied | 95 gal | 100 gal |
| Water with a bather (typical) | 55-85 gal | 45-70 gal |
What is different
- The Companion is 2 3/8 in. wider than the Ultimate (32 in. vs 29 5/8 in.).
- The Companion is 0 1/2 in. longer than the Ultimate (60 in. vs 59 1/2 in.).
- The Companion is 4 1/4 in. taller than the Ultimate (40 in. vs 35 3/4 in.).
- They share the same door design: stainless steel removable inward-swing door.
- The Companion seats two bathers; the Ultimate is a single-seat tub.
- To the overflow, the Ultimate holds about 95 gallons and the Companion about 100, which matters for water heater sizing.
- Net weights are 220 lb (Ultimate) and 251 lb (Companion).
Common questions
Which is bigger, the Ultimate or the Companion?
The Companion has the larger footprint at 32" x 60" x 40", against 29.625" x 59.50" x 35.75" for the Ultimate.
Do the Ultimate and the Companion have the same door?
Yes. Both use the stainless steel removable inward-swing door, so the same operation, seal and latch guides apply to either tub.
How much water do the Ultimate and the Companion hold?
To the overflow when empty, the Ultimate holds about 95 gallons and the Companion about 100 gallons; with a bather the typical ranges are 55-85 and 45-70 gallons. Size your water heater to the larger figure.
Can two people bathe in the Companion?
Yes. The Companion is a two-seat tub; the Ultimate seats one bather.
Read the full profiles
Add a third model to this comparison → · Dimensions by model · Which door does my tub have?
Want help choosing?
Your Ella dealer or the team at (800) 480-6850 can walk you through both tubs for your space and needs.
