Petite vs Escape: Walk-In Tub Comparison
The Ella Petite and the Ella Escape side by side, using the actual dimensions from the spec sheets and technical drawings rather than nominal sizes. The profiles cover therapy packages, videos and installation notes for each tub.
VS
| Door style | Stainless steel removable inward-swing door | Stainless steel removable inward-swing door |
| Door swing | Inward | Inward |
| Seats | One bather | Two bathers |
| Actual size (W x L x H) | 27.5" x 52" x 35" | 36" x 72" x 40" |
| Seat | 19" x 13 in. | 27" and 29" |
| Interior length | 45 1/2 in. | 63 7/8 in. |
| Seat to overflow (soaking depth) | 15 3/8 in. | 18 1/2 in. |
| Seat to footwell | 15 in. | 15 in. |
| Footwell | 17 W by 21 L | not listed |
| Net weight | 200 lb | 286 lb |
| Shipping weight | 305 lb | 398 lb |
| Crate size (W x L x H) | 31" x 57" x 47" | 40" x 76" x 49" |
| Water to overflow, unoccupied | 65 gal | 145 gal |
| Water with a bather (typical) | 30-50 gal | 85-135 gal |
What is different
- The Escape is 8 1/2 in. wider than the Petite (36 in. vs 27 1/2 in.).
- The Escape is 20 in. longer than the Petite (72 in. vs 52 in.).
- The Escape is 5 in. taller than the Petite (40 in. vs 35 in.).
- They share the same door design: stainless steel removable inward-swing door.
- The Escape seats two bathers; the Petite is a single-seat tub.
- To the overflow, the Petite holds about 65 gallons and the Escape about 145, which matters for water heater sizing.
- Net weights are 200 lb (Petite) and 286 lb (Escape).
Common questions
Which is bigger, the Petite or the Escape?
The Escape has the larger footprint at 36" x 72" x 40", against 27.5" x 52" x 35" for the Petite.
Do the Petite and the Escape have the same door?
Yes. Both use the stainless steel removable inward-swing door, so the same operation, seal and latch guides apply to either tub.
How much water do the Petite and the Escape hold?
To the overflow when empty, the Petite holds about 65 gallons and the Escape about 145 gallons; with a bather the typical ranges are 30-50 and 85-135 gallons. Size your water heater to the larger figure.
Can two people bathe in the Escape?
Yes. The Escape is a two-seat tub; the Petite seats one bather.
