Elite vs Transfer26: Walk-In Tub Comparison
The Ella Elite and the Ella Transfer26 side by side, using the actual dimensions from the spec sheets and technical drawings rather than nominal sizes. The profiles cover therapy packages, videos and installation notes for each tub.
VS
| Door style | Stainless steel removable inward-swing door | L-shape outward-swing transfer door |
| Door swing | Inward | Outward |
| Seats | One bather | One bather |
| Actual size (W x L x H) | 30" x 52" x 35" | 26" x 52" x 40" |
| Seat | 22" x 12 1/4 in. | 19" x 16 3/4 in. |
| Interior length | 45 in. | 43 5/8 in. |
| Seat to overflow (soaking depth) | 15 1/2 in. | 17 1/2 in. |
| Seat to footwell | 15 in. | 17 in. |
| Footwell | 17 W by 20 1/2 L | 15 1/2 W by 17 1/2 L |
| Net weight | 205 lb | 205 lb |
| Shipping weight | 230 lb | 300 lb |
| Crate size (W x L x H) | 32" x 54" x 50" | 29" x 60" x 50" |
| Water to overflow, unoccupied | 75 gal | 75 gal |
| Water with a bather (typical) | 35-55 gal | 35-55 gal |
What is different
- The Elite is 4 in. wider than the Transfer26 (30 in. vs 26 in.).
- Both are 52 in. long.
- The Transfer26 is 5 in. taller than the Elite (40 in. vs 35 in.).
- Door designs differ: the Elite has the stainless steel removable inward-swing door and the Transfer26 has the l-shape outward-swing transfer door.
- Both hold about 75 gallons to the overflow when empty.
- Net weights are 205 lb (Elite) and 205 lb (Transfer26).
Common questions
Which is bigger, the Elite or the Transfer26?
The Elite has the larger footprint at 30" x 52" x 35", against 26" x 52" x 40" for the Transfer26.
Do the Elite and the Transfer26 have the same door?
No. The Elite uses the stainless steel removable inward-swing door and the Transfer26 uses the l-shape outward-swing transfer door, so the door guides differ.
How much water do the Elite and the Transfer26 hold?
To the overflow when empty, the Elite holds about 75 gallons and the Transfer26 about 75 gallons; with a bather the typical ranges are 35-55 and 35-55 gallons. Size your water heater to the larger figure.
Read the full profiles
Add a third model to this comparison → · Dimensions by model · Which door does my tub have?
Want help choosing?
Your Ella dealer or the team at (800) 480-6850 can walk you through both tubs for your space and needs.
